本机适合多品种、大中批量生产工件的表面除锈或抛丸强化。清理工件必须是不怕碰撞的铸件及热处理件。该机既可单机使用，又可配线使用。
This machine is in keeping with many species,big medium the batch quantity produces the surface of the work piece in addition to becoming rusty or throwing the pill to enhance.Tidy up the work picec piece and the hot processing pieces that musts be the not afraid collision.That machine since can single machine usage,can go together with the line usage again
技术参数 Technical parameters
项目 单位 Q326C Q3210C QR3210
生产率 t/h 0.6~1.2 3~5 1.5~2.5
加料量 kg 200 800 600
单件最大重量 kg 10 150 30
端盘直径 mm Φ650 Φ1000 Φ1000
有效容积 m³ 0.15 0.4 0.3
抛丸量 kg/min 100 250 250
除尘量 m³/h 2200 6000 5000
功率消耗 kw 12.6 32.6 24.3
外形尺寸 mm 3681×1650×5800 3644×2926×5856 3972×2600×4768
|
